產品型號: FTAH-490/FTGH-490 中文產品說明: 1.有效容積:約490L (± 1L) 2.外箱尺寸:W600.D705.H1374 mm (± 2mm) (含活動輪及剎車輪各二組) 3.內箱尺寸:W598.D680.H1204 mm (± 2mm) 4.控制方式:全功能微電腦電子控制,觸摸式薄膜按鍵調節控制濕度 5.顯示方式:兩組數位LED顯示器,即時顯示櫃內“溫度”及“濕度” 6.除濕方式:全自動吸濕.排濕(分子篩)+記憶合金驅動 7.斷電記憶:不受斷電的影響而使設定值改變 8.濕度控制範圍:20%-60%RH 30%~60%RH (FTGH) 9.除濕能力:最低可達20%RH (±5%RH) 最低可達30%RH (±5%RH) (FTGH) 10.主機設計:分離式,DIY拆卸簡便 11.材質:箱體厚1.0mm鋼板防鏽粉體烤漆 12.門:二門,3MM正牌安全強化玻璃 13.電源:AC110V或220V, 50/60HZ 14.隔板:3片 (上下高低可調) 15.認證證書:ISO9001:2008, CE, UL DESCRIPTION: Capacity:490L (± 1L) External Dimension:W600.D705.H1374 mm (± 2mm) (W/CASTOR) Internal Dimension:W598.D680.H1204 mm (± 2mm) RH Control:Touchable buttons,20~60% RH stepless adjustment by 1%RH RH Display:Digital LED display for current interior humidity & temperature Dehumidify Way:Memorial Alloy Dehumidification System Power Failure Condition:Power cut-off, moisture absorbs continuously with sustention for 24hrs. RH Control Range:20%~60%RH 30%~60%RH (FTGH) Dehumidify Ability: Approx. 20%RH (minimum) (±5%RH) Approx. 30%RH (minimum) (±5%RH) (FTGH) Dry Unit design:Easy to disassemble (DIY). Cabinet Body:Galvanized steel plate 1.0mm steel with anti-rusty powder coating Door:2 Doors,PVC frame magnet gasket Power Source:AC110V or 220V, 50/60HZ Shelf:3 pcs (Adjustable up/down) 15.Guarantee:1 Year on Dry Unit & 1 year on Body. (Excluded carriage from parts of dry cabinet.) (Guarantee will not apply to the damages caused by nature disasters, faulty usages or consumable purposes.) 16.Certification:ISO9001:2008, CE, UL
產品型號: FTAH-240/FTGH-240 中文產品說明: 1.有效容積:約240L (± 1L) 2.外箱尺寸:W600.D705.H680 mm (± 2mm) 3.內箱尺寸:W598.D680.H610 mm (± 2mm) 4.控制方式:全功能微電腦電子控制,觸摸式薄膜按鍵調節控制濕度 5.顯示方式:兩組數位LED顯示器,即時顯示櫃內“溫度”及“濕度” 6.除濕方式:全自動吸濕.排濕(分子篩)+記憶合金驅動 7.斷電記憶:不受斷電的影響而使設定值改變 8.濕度控制範圍:20%-60%RH 30%~60%RH (FTGH) 9.除濕能力:最低可達20%RH (±5%RH) 最低可達30%RH (±5%RH) (FTGH) 10.主機設計:分離式,DIY拆卸簡便 11.材質:箱體厚1.0mm鋼板防鏽粉體烤漆 12.門:一門,3MM正牌安全強化玻璃 13.電源:AC110V或220V, 50/60HZ 14.隔板:1片 (上下高低可調) 15.認證證書:ISO9001:2008, CE, UL DESCRIPTION: Capacity:240L (± 1L) External Dimension:W600.D705.H680 mm (± 2mm) Internal Dimension:W598.D680.H610 mm (± 2mm) RH Control:Touchable buttons,20~60% RH stepless adjustment by 1%RH RH Display:Digital LED display for current interior humidity & temperature Dehumidify Way:Memorial Alloy Dehumidification System Power Failure Condition:Power cut-off, moisture absorbs continuously with sustention for 24hrs. RH Control Range:20%~60%RH 30%~60%RH (FTGH) Dehumidify Ability:Approx. 20%RH (minimum) (±5%RH) Approx. 30RH (±5%RH)(FTGH) Dry Unit design:Easy to disassemble (DIY). Cabinet Body:Galvanized steel plate 1.0mm steel with anti-rusty powder coating Door:1 Door,PVC frame magnet gasket Power Source:AC110V or 220V, 50/60HZ Shelf:1 pce (Adjustable up/down) 15.Guarantee:1 Year on Dry Unit & 1 year on Body. (Excluded carriage from parts of dry cabinet.) (Guarantee will not apply to the damages caused by nature disasters, faulty usages or consumable purposes.) 16.Certification:ISO9001:2008, CE, UL
產品型號: FTAH-716/FTGH-716 中文產品說明: 1.有效容積:約788L (± 1L) 2.外箱尺寸:W1400.D600.H1150 mm (± 2mm) (含活動輪及剎車輪各二組) 3.內箱尺寸:W1398.D575.H980 mm (± 2mm) 4.控制方式:全功能微電腦電子控制,觸摸式薄膜按鍵調節控制濕度 5.顯示方式:兩組數位LED顯示器,即時顯示櫃內“溫度”及“濕度” 6.除濕方式:全自動吸濕.排濕(分子篩)+記憶合金驅動 7.斷電記憶:不受斷電的影響而使設定值改變 8.濕度控制範圍:20%-60%RH 30%~60%RH (FTGH) 9.除濕能力:最低可達20%RH (±5%RH) 最低可達30%RH (±5%RH) (FTGH) 10.主機設計:分離式,DIY拆卸簡便 11.材質:箱體厚1.0mm鋼板防鏽粉體烤漆 12.門:二門,3MM正牌安全強化玻璃 13.電源:AC110V或220V, 50/60HZ 14.隔板:3片 (上下高低可調) 15.認證證書:ISO9001:2008, CE, UL DESCRIPTION: Capacity:788L (± 1L) External Dimension:W1400.D600.H1150 mm (± 2mm) (W/CASTOR) Internal Dimension:W1398.D575.H980 mm (± 2mm) RH Control:Touchable buttons,20~60% RH stepless adjustment by 1%RH RH Display:Digital LED display for current interior humidity & temperature Dehumidify Way:Memorial Alloy Dehumidification System Power Failure Condition:Power cut-off, moisture absorbs continuously with sustention for 24hrs. RH Control Range:20%~60%RH 30%~60%RH (FTGH) Dehumidify Ability: Approx. 20%RH (minimum) (±5%RH) Approx. 30%RH (minimum) (±5%RH) (FTGH) Dry Unit design:Easy to disassemble (DIY). Cabinet Body:Galvanized steel plate 1.0mm steel with anti-rusty powder coating Door:2 Doors,PVC frame magnet gasket Power Source:AC110V or 220V, 50/60HZ Shelf:3 pcs (Adjustable up/down) 15.Guarantee:1 Year on Dry Unit & 1 year on Body. (Excluded carriage from parts of dry cabinet.) (Guarantee will not apply to the damages caused by nature disasters, faulty usages or consumable purposes.) 16.Certification:ISO9001:2008, CE, UL
產品型號: FTAH-516/FTGH-516 中文產品說明: 1.有效容積:約516L (± 1L) 2.外箱尺寸:W1250.D485.H950 mm (± 2mm) 3.內箱尺寸:W1248.D460.H900 mm (± 2mm) 4.控制方式:全功能微電腦電子控制,觸摸式薄膜按鍵調節控制濕度 5.顯示方式:兩組數位LED顯示器,即時顯示櫃內“溫度”及“濕度” 6.除濕方式:全自動吸濕.排濕(分子篩)+記憶合金驅動 7.斷電記憶:不受斷電的影響而使設定值改變 8.濕度控制範圍:20%-60%RH 30%~60%RH (FTGH) 9.除濕能力:最低可達20%RH (±5%RH) 最低可達30%RH (±5%RH) (FTGH) 10.主機設計:分離式,DIY拆卸簡便 11.材質:箱體厚1.0mm鋼板防鏽粉體烤漆 12.門:二門,3MM正牌安全強化玻璃 13.電源:AC110V或220V, 50/60HZ 14.隔板:3片 (上下高低可調) 15.認證證書:ISO9001:2008, CE, UL DESCRIPTION: Capacity:516L (± 1L) External Dimension:W1250.D485.H950 mm (± 2mm) Internal Dimension:W1248.D460.H900 mm (± 2mm) RH Control:Touchable buttons,20~60% RH stepless adjustment by 1%RH RH Display:Digital LED display for current interior humidity & temperature Dehumidify Way:Memorial Alloy Dehumidification System Power Failure Condition:Power cut-off, moisture absorbs continuously with sustention for 24hrs. RH Control Range:20%~60%RH 30%~60%RH (FTGH) Dehumidify Ability: Approx. 20%RH (minimum) (±5%RH) Approx. 30%RH (minimum) (±5%RH) (FTGH) Dry Unit design:Easy to disassemble (DIY). Cabinet Body:Galvanized steel plate 1.0mm steel with anti-rusty powder coating Door:2 Doors, PVC frame magnet gasket Power Source:AC110V or 220V, 50/60HZ Shelf:3 pcs (Adjustable up/down) 15.Guarantee:1 Year on Dry Unit & 1 year on Body. (Excluded carriage from parts of dry cabinet.) (Guarantee will not apply to the damages caused by nature disasters, faulty usages or consumable purposes.) 16.Certification:ISO9001:2008, CE, UL
產品型號: FTAH-308M/FTGH-308M 中文產品說明: 1.有效容積:約310L (± 1L) 2.外箱尺寸:W905.D425.H940 mm (± 2mm) 3.內箱尺寸:W903.D400.H860 mm (± 2mm) 4.控制方式:全功能微電腦電子控制,觸摸式薄膜按鍵調節控制濕度 5.顯示方式:兩組數位LED顯示器,即時顯示櫃內“溫度”及“濕度” 6.除濕方式:全自動吸濕.排濕(分子篩)+記憶合金驅動 7.斷電記憶:不受斷電的影響而使設定值改變 8.濕度控制範圍:20%-60%RH 30%~60%RH (FTGH) 9.除濕能力:最低可達20%RH (±5%RH) 最低可達30%RH (±5%RH) (FTGH) 10.主機設計:分離式,DIY拆卸簡便 11.材質:箱體厚1.0mm鋼板防鏽粉體烤漆 12.門:二鐵門,3MM正牌安全強化玻璃 13.電源:AC110V或220V, 50/60HZ 14.隔板:3片 (上下高低可調) 15.認證證書:ISO9001:2008, CE, UL DESCRIPTION: Capacity:310L (± 1L) External Dimension:W905.D425.H940 mm (± 2mm) Internal Dimension:W903.D400.H860 mm (± 2mm) RH Control:Touchable buttons,20~60% RH stepless adjustment by 1%RH RH Display:Digital LED display for current interior humidity & temperature Dehumidify Way:Memorial Alloy Dehumidification System Power Failure Condition:Power cut-off, moisture absorbs continuously with sustention for 24hrs. RH Control Range:20%~60%RH 30%~60%RH (FTGH) Dehumidify Ability: Approx. 20%RH (minimum) (±5%RH) Approx. 30%RH (minimum) (±5%RH) (FTGH) Dry Unit design:Easy to disassemble (DIY). Cabinet Body:Galvanized steel plate 1.0mm steel with anti-rusty powder coating Door:2 Iron Doors,PVC frame magnet gasket Power Source:AC110V or 220V, 50/60HZ Shelf:3 pcs (Adjustable up/down) 15.Guarantee:1 Year on Dry Unit & 1 year on Body. (Excluded carriage from parts of dry cabinet.) (Guarantee will not apply to the damages caused by nature disasters, faulty usages or consumable purposes.) 16.Certification:ISO9001:2008, CE, UL
產品型號: FTAH-308/FTGH308 中文產品說明: 1.有效容積:約310L (± 1L) 2.外箱尺寸:W905.D425.H940 mm (± 2mm) 3.內箱尺寸:W903.D400.H860 mm (± 2mm) 4.控制方式:全自動控制,無段旋鈕調整 5.顯示方式:濕度指針表,即時顯示櫃內濕度 6.除濕方式:全自動吸濕.排濕(分子篩)+記憶合金驅動 7.斷電記憶:不受斷電的影響而使設定值改變 8.濕度控制範圍:20%-60%RH 30%~60%RH (FTGH) 9.除濕能力:最低可達20%RH (±5%RH) 最低可達30%RH (±5%RH) (FTGH) 10.主機設計:分離式,DIY拆卸簡便 11.材質:箱體厚1.0mm鋼板防鏽粉體烤漆 12.門:二門,3MM正牌安全強化玻璃 13.電源:AC110V或220V, 50/60HZ 14.隔板:3片 (上下高低可調) 15.認證證書:ISO9001:2008, CE, UL DESCRIPTION: Capacity:310L (± 1L) External Dimension:W905.D425.H940 mm (± 2mm) Internal Dimension:W903.D400.H860 mm (± 2mm) RH Control:Knob controller (Adjustable) RH Display:Gauge display for current interior humidity Dehumidify Way:Memorial Alloy Dehumidification System Power Failure Condition:Power cut-off, moisture absorbs continuously with sustention for 24hrs. RH Control Range:20%~60%RH 30%~60%RH (FTGH) Dehumidify Ability: Approx. 20%RH (minimum) (±5%RH) Approx. 30%RH (minimum) (±5%RH) (FTGH) Dry Unit design:Easy to disassemble (DIY). Cabinet Body:Galvanized steel plate 1.0mm steel with anti-rusty powder coating Door:2 Doors,PVC frame magnet gasket, 3mm safe tempered glass Power Source:AC110V or 220V, 50/60HZ Shelf:3 pcs (Adjustable up/down) 15.Guarantee:1 Year on Dry Unit & 1 year on Body. (Excluded carriage from parts of dry cabinet.) (Guarantee will not apply to the damages caused by nature disasters, faulty usages or consumable purposes.) 16.Certification:ISO9001:2008, CE, UL
特色:●新穎立式設計,箱體外殼採用冷軋鋼板製作,表面經粉體塗裝處理,造型美觀兼具耐用。●獨特底部散風與底部加熱器組合,渦輪離心式循環,有效延長風扇壽命,並經配獨特風道,使箱體內部溫度更加均勻,在達溫度值後,可關閉循環風扇。●不鏽鋼內相四角呈弧形,表面經防鏽處理,可上下調整層板高度,風道側板與底部加熱罩獨特快拆式結構設計便於清潔。●PID微電腦控溫器具有定時超溫警報雙顯示器功能,控溫精確具有停電記憶裝置,復電及恢復功能。●箱門中間裝有雙層耐震動大型玻璃觀測窗,配以鎖扣鬆緊調節門鎖,耐高溫SIKICON密封膠條,確保良好密封性,防止熱氣流失。●採用低噪音熱風馬達。 型號 FT-65B FT-125B FT-230B 電源電壓 220V AC 50HZ 控制範圍 RT+5~300℃ 溫度精度 ±1℃ 加熱功率 1.5KW 2.3KW 3KW 內部尺寸 400X360X450mm 500X450X550mm 600X500X750mm 外部尺寸 550X550X840mm 636X680X915mm 730X670X1120mm 重量 46kg 64kg 76kg 計時器 1~99min 棚板 2PCS 視窗 YES ►型錄下載
◆不需要加潤滑油免維護 ◆無油活塞式真空幫浦,感應馬達,扭力強、效率高。 真空壓力可達680毫米汞柱,幫浦使用110伏特電壓最大流速為每分鐘22公升, 使用220伏特電壓,每分鐘18公升。 型號Vs01真空幫浦的功率高於其他廠牌,可以達70瓦,機器重量4.1公斤, 型號Vs08為11公斤,非常輕巧。 ◆具直覺式電源開關、調壓閥設定簡單易用。 ◆幫浦馬達,內建過熱保護裝置,在電壓低時自切斷電源,保護馬達與使用者安全。 ◆具備國際安全認證 ★歐盟 CE 安全認證 ★北美 CSA 安全認證 ★美國最具權威安全試驗所UL安全規範 ◆產品特色 ★高耐腐蝕性,一機抵二機 ★無油活塞式設計,完全無汙染 ★使用吸振馬達,低噪音運轉 ★耐用,不需加油及保養 ★過載保護裝置 ★備有調壓閥,方便隨時調壓 ★台灣製 ◆產品應用實驗室儀器、醫療儀器、化學分析、環境分析、微生物檢測、水質分析、空氣採樣、真空抽濾、各式樣本前處理實驗 ◆產品規格 ◆產品示意圖 ▲點圖放大 ◆型錄下載1 ◆型錄下載2
