Arch Size 600W x 1050H mm (Aluminum Arch) (Optional: Stainless Steel Arch) Power Supply 110V/220V/1 Phase, 220V/380V/415V 3 Phase Strap Cycle Speed 26 Cycles / Min. (60HZ) (It depends on the package size) Dimension 1395W x 640D x 1810Hmm Strap Width 9-15 mm (Change kits and adjustment) Tension Strength Max. 70 Kg Sealing Method Heat Sealing

Arch Size 600W x 630H mm (Standard) Strap Cycle Speed 28 Straps /60 Sec. Tension Strength Max. 70Kgs Table Height 585~685mm Strap Width 6~15mm Sealing Method Heat Sealing Power Supply 110/220V 50/60Hz 1Ph; 220/380V 50/60Hz 3Ph Dimensions 1410W x 640D x 1810H mm Machine Weight 287Kgs Packing Size 600W x 530-630H mm

Arch Size 1200W X 2800H mm (Metal Cover Arch)(Optional) Power Supply 110/220V 50/60Hz 1Ph; 220/380V 50/60Hz 3Ph Strap Cycle Speed 3 Sec./Strap(60Hz)(It depends on the package size) Dimensions 2745W x 640D x 3365H mm Strap Width 12,15 or 19mm Tension Strength Max. 70Kgs Sealing Method Heat Sealing

Arch Size 600W x 850H mm (Standard) Strap Cycle Speed 28 Straps /60 sec Tension Strength Max. 70Kgs Strap Width 9~15mm Sealing Method Heat Sealing Power Supply 110/220V 50/60Hz 1Ph; 220/380V 50/60Hz 3Ph Dimensions 1400W x 640D x 1740H mm Packing Size 30-600W x 100-850H mm

Strap Guide Length 1000mm Min. Packaging Height 550mm

Arch Size 650W x 400H mm (Optional) Tension Strength Max.70Kgs Table Height 820mm Strap Width 6~15.5mm Pressure 5kg/cm2 (Bar) Sealing Method Heat Sealing Cylinder Inner Diameter: Ø40 Power Supply 110/220V 50/60Hz lPh; 220/380V 50/60Hz 3Ph Max. Package 300W x 350Hmm Min. Package 120W x 100Hmm

Arch Size 1050W x 600H mm (Optional) Table Height 810mm Strap Width 9~15.5mm Pressure 5kg/cm2 (Bar) Sealing Method Heat Sealing Cylinder Inner Diameter: Ø40 Stroke 550mm Power Supply 110/220V 50/60Hz lPh; 220/380V 50/60Hz 3Ph Max. Package 1000W x 560Hmm Min. Package 300W x 100Hmm

Arch Size 1650W x 600H mm(Optional) Table Height 810mm Strap Width 9~15.5mm Pressure 5kg/cm2 (Bar) Sealing Method Heat Sealing Cylinder Inner Diameter: Ø40 Stroke 550mm Power Supply 110/220V 50/60Hz lPh; 220/380V 50/60Hz 3Ph Dimensions 2350W x 800D x 2300Hmm

Arch Size 850W x 600H mm (Standard) Strap Cycle Speed 2.5 Sec./ cycle Tension Strength Max. 70kgs Table Height 450mm or 500mm Strap Width 9~15.5mm Sealing Method Heat Sealing Power Roller Speed 18M/60Hz, 15M/50Hz Per Min. Packing Size 200-520W , 30-560H mm Power Supply 110/220V 50/60Hz 1Ph; 220/380V 50/60Hz 3Ph Dimensions 1940W x 640D x 1670H mm Machine Weight 307kgs Gross Weight 402kgs

Basic functions are as same as JN-85PBU-2HT (Standard)   The table height can be re-designed from H650 to H800 mm accordingly.   Equipped with another one ??Table Auto-Stop?? Photocell (PH 0). The PH 0 photocell should be equipped on the input (belt driving or roller driving) conveyor. When there is no any packages on the machine within 30 sec., the power table will stop driving for a while. When the packages come again, the input conveyor and JN-85PBU-2HT will re-start automatically via the PH 0 photocell. (Optional)   Equipped with 4 supporters (Optional)

Arch Size 850W x 600H mm (Standard) Strap Cycle Speed 2.5 Sec/cycle Tension Strength Max. 70kgs Table Height 450mm or 500mm Strap Width 9~15.5mm Sealing Method Heat Sealing Power Roller Speed 13M/60Hz, 10.5M/50Hz Per Min. Packing Size 300-820W , 30-560Hmm Power Supply 110/220V 50/60Hz 1Ph; 220/380V 50/60Hz 3Ph Dimensions 1940W x 800D x 1670H mm Machine Weight 307kgs Gross Weight 402kgs

Arch Size 850W x 600H mm (Standard) Strap Cycle Speed 2.5 Sec/cycle Tension Strength Max. 70kgs Table Height 810mm Strap Width 9~15.5mm Sealing Method Heat Sealing Power Roller Speed 13M/60Hz, 10.5M/ 50Hz Per Min. Package Size 300~820W , 30~560H Power Supply 110/220V 50/60Hz 1Ph; 220/380V 50/60Hz 3Ph Dimensions 1550W x 800D x 1470H mm Machine Weight 330Kgs Gross Weight 430Kgs

Arch Size 850W x 800H mm (Standard) Power Supply 110V/220V/1 Phase, 220V/380V/415V 3 Phase Dimension 1760W x 640D x 2700H (Standard) Strap Width 9-15 mm (Change kits and adjustment) Oil Cylinder Ø50 x 750L mm per piece (2 pieces/ machine) Tension Strength Max. 70 Kg Table Height 810 mm Sealing Method Heat Sealing

Arch Size 850W x 600H mm (Standard) Strap Cycle Speed 8 Sec./ Cycle Tension Strength Max. 70kgs Table Height 805mm Strap Width 6~15.5mm Pressure 5kg/cm2 (Bar) Sealing Method Heat Sealing Cylinder Inner Diameter: Ø40 Stroke 550mm Power Supply 110/220V 50/60Hz 1Ph; 220/380V 50/60Hz 3Ph Dimensions 1450W x 640D x 2140H /mm Machine Weight 315kgs Gross Weight 432kgs

Arch Size 850W x 600H mm (Standard) Strap Cycle Speed 28 Cycles/ 60Hz, 26 cycles/ 50Hz per Min Tension Strength Max. 70kgs Table Height 805mm Strap Width 6~15.5mm Sealing Method Heat Sealing Power Supply 110/220V 50/60Hz 1Ph; 220/380V 50/60Hz 3Ph Dimensions 1400W x 640D x 1475H mm Machine Weight 220kgs Gross Weight 265kgs

Arch Size 650W x 400H mm (Standard)

Arch Size 850W x 600H mm (Standard) Tension Strength Max. 70kgs Strap Cycle Speed 28 Cycles/ 60Hz, 26 cycles/ 50Hz per Min Table Height 805mm Strap Width 6~15.5mm Sealing Method Heat Sealing Power Supply 110/220V 50/60Hz 1Ph; 220/380V 50/60Hz 3Ph Dimensions 1400W x 640D x 1475H mm Machine Weight 220kgs Gross Weight 265kgs

Arch Size 850W x 600H mm (Standard) (Aluminum arch cover) Power Supply 110V/220V/1 Phase, 220V/380V/415V 3 Phase Strap Cycle Speed 28-30 Cycles / Min. (60HZ) (It depends on the package size) Dimension 1400Wx 640D x 1475H (Standard) Strap Width 6-15 mm (Change kits and adjustment) Tension Strength Max. 70 Kg Table Height 805 mm Available Packing Size 100-825W x 30-580H mm Machine Net Weight 220 Kg Sealing Method Heat Sealing

Machine Size 900(W)x640(D)x1170(H)mm Arch Size 750Wx800H mm Strap Cycle Speed 30 straps/Min. (50/60HZ) Voltage 110/220V/1 Phase. 220V/380V/415V 3 Phase Tension Strength 10-75 Kg Strap Width 6-15mm (Change kits and adjustment) Packing Size 100-700mm (Width) x 30-775mm (Height) (When packing width is samller than 100mm or packing height is smaller than 30mm, mechanical disign will be re-made accordingly)
