Designed to cut hard and soft wood. Has a flat tooth pattern or an alternative tooth pattern with 20° hook (face) angle. Performs high speed ripping leaving a rough edge. Used in circular saw benches and multi rip saw machines. Diameter (mm) Kerf (mm) Bore Teeth 110 2.4 5/8" 12 140 2.4 5/8" 12 152 2.4 5/8" 16 184 2.4 5/8" 16 203 2.6 5/8" 18 230 3.2 5/8" 20 255 3.2 5/8" 24 305 3.6 1" 30 355 3.6 1" 36 406 4.0 1" 40 455 4.0 1" 40
This blade is manufactured with good steel and carbide. Diameter (mm) Kerf (mm) Bore Teeth 184 2.0 5/8" 24 184 2.0 5/8" 40 203 2.0 5/8" 40 230 2.4 5/8" 40 255 2.4 5/8" 40
For cutting against the grain slow cutting feed. Designed for two sided laminate veneer, and plastic material. Has 5°hook (face) angle for exceptional cutting quality. Diameter (mm) Kerf (mm) Bore Teeth 255 3.2 5/8" 60 255 3.2 5/8" 80 305 3.2 1" 60 305 3.2 1" 96 355 3.4 1" 80 355 3.4 1" 100 406 3.4 1" 80 406 3.4 1" 100 455 3.6 1" 80 455 3.6 1" 100
This saw blade is designed by TC and ATB; used for cutting various soft steels, solid bat materials, and metals. Diameter (mm) Kerf (mm) Bore Teeth 110 1.7 20 24 110 1.7 20 40 160 1.7 20 28 180 2.0 20 36 180 2.0 20 40 205 2.2 25.4 40 255 2.2 25.4 60 255 2.2 25.4 72 305 2.6 25.4 60 355 2.6 25.4 60 355 2.6 25.4 72
This saw blade is designed by TC and ATB; used for cutting iron pipes and stainless steels.
Carbide Tipped Circular Saw with Triplechip tooth and negative hook for thin walled profiles of plastic. For thick wall, use less teeth. Diameter (mm) Kerf (mm) Bore Teeth 255 3.0 5/8" 60 255 3.0 5/8" 80 305 3.0 1" 60 305 3.0 1" 96 355 3.2 1" 80 355 3.2 1" 100 406 3.2 1" 80 406 3.2 1" 100 455 3.4 1" 80 455 3.4 1" 100
For general cutting and trimming of wood, plywood, and sizing pressboard, hardboard, chipboard and particle board, when a nice cut is needed. This blade is furnished with 10° to 20° hook (face) angle for fast feed giving a reasonable finish. For table saws, overhead saws, and radial arm saws Diameter (mm) Kerf (mm) Bore Teeth 110 2.4 5/8" 30 140 2.4 5/8" 30 152 2.4 5/8" 30 184 2.4 5/8" 40 184 2.4 5/8" 40 203 2.8 5/8" 36 203 2.8 5/8" 48 230 2.8 5/8" 48 230 2.8 5/8" 60 255 3.2 5/8" 60 255 3.2 5/8" 80 305 3.2 1" 60 305 3.2 1" 96 355 3.4 1" 80 355 3.4 1" 100 406 3.4 1" 80 406 3.4 1" 100 455 4.0 1" 80 455 4.0 1" 100
Carbide Tipped Circular Saw with Triplechip tooth and negative hook for thin walled profiles of aluminum. Diameter (mm) Kerf (mm) Bore Teeth 184 2.4 5/8" 14 203 2.8 5/8" 18 230 2.8 5/8" 20 255 3.0 5/8" 24 305 3.0 1" 24 355 3.2 1" 36
All purpose blade designed for ripping, cutting along and across the grain for easy feed in softwood, plywood, chipboard and particle board. The fifth raker tooth is designed to give a clean medium quality cut. For radial arm and table saws. Diameter (mm) Kerf (mm) Bore Teeth 184 2.4 5/8" 35 210 2.6 5/8" 35 230 2.8 5/8" 40 250 2.8 5/8" 50
For cutting aluminum sheets, tubing extrusions and other non ferrous metals such as copper, brass, lead and magnesium. For smooth cutting, use lots of lubricant and a clamping devise. Diameter (mm) Kerf (mm) Bore Teeth 255 3.0 5/8" 60 255 3.0 5/8" 80 305 3.0 1" 60 305 3.0 1" 96 355 3.2 1" 80 355 3.2 1" 100 406 3.2 1" 80 406 3.2 1" 100 455 3.4 1" 80 455 3.4 1" 100
此鋸片是以TC的設計，具負數的腹面角度，專用於薄片塑膠的切割。 直徑 (mm) 刃厚 (mm) 孔徑 齒數 255 3.0 5/8" 60 255 3.0 5/8" 80 305 3.0 1" 60 305 3.0 1" 96 355 3.2 1" 80 355 3.2 1" 100 406 3.2 1" 80 406 3.2 1" 100 455 3.4 1" 80 455 3.4 1" 100
此鋸片是以TC和ATB的設計，專於切割各種軟鋼材和實心棒材等金屬材料。 直徑 (mm) 刃厚 (mm) 孔徑 齒數 110 1.7 20 24 110 1.7 20 40 160 1.7 20 28 180 2.0 20 36 180 2.0 20 40 205 2.2 25.4 40 255 2.2 25.4 60 255 2.2 25.4 72 305 2.6 25.4 60 355 2.6 25.4 60 355 2.6 25.4 72
適用鋁片、管類和其他非鐵材例如銅、鉛和鎂。為使切割滑順，可使用潤滑油和夾鉗。 直徑 (mm) 刃厚 (mm) 孔徑 齒數 255 3.0 5/8" 60 255 3.0 5/8" 80 305 3.0 1" 60 305 3.0 1" 96 355 3.2 1" 80 355 3.2 1" 100 406 3.2 1" 80 406 3.2 1" 100 455 3.4 1" 80 455 3.4 1" 100
此鋸片是以M-TC的設計，具負數的腹面角度，專用於薄面鋁材的切割。 直徑 (mm) 刃厚 (mm) 孔徑 齒數 184 2.4 5/8" 14 203 2.8 5/8" 18 230 2.8 5/8" 20 255 3.0 5/8" 24 305 3.0 1" 24 355 3.2 1" 36
此鋸片具有5°的腹面角度，用於切割硬紙板、硬木、樹木、蟻酸及其他的塑膠面板。 直徑 (mm) 刃厚 (mm) 孔徑 齒數 255 3.2 5/8" 60 255 3.2 5/8" 80 305 3.2 1" 60 305 3.2 1" 96 355 3.4 1" 80 355 3.4 1" 100 406 3.4 1" 80 406 3.4 1" 100 455 3.6 1" 80 455 3.6 1" 100
此鋸片用於切割軟木、合板及特殊板材。第五顆齒是專為提供清除木屑之用。 專供旋臂式鋸台和桌式鋸台用。 直徑 (mm) 刃厚 (mm) 孔徑 齒數 184 2.4 5/8" 35 210 2.6 5/8" 35 230 2.8 5/8" 40 250 2.8 5/8" 50
鋸片為一般薄型及防逆轉加散熱孔的設計 直徑 (mm) 刃厚 (mm) 孔徑 齒數 184 2.0 5/8" 24 184 2.0 5/8" 40 203 2.0 5/8" 40 230 2.4 5/8" 40 255 2.4 5/8" 40
一般切斷和修整木材，合板和特殊板材，可做為優質的切割。 鋸片為10°至20°腹面角度，適用於桌上鋸台、高架鋸台和旋臂式鋸台。 直徑 (mm) 刃厚 (mm) 孔徑 齒數 110 2.4 5/8" 30 140 2.4 5/8" 30 152 2.4 5/8" 30 184 2.4 5/8" 40 184 2.4 5/8" 40 203 2.8 5/8" 36 203 2.8 5/8" 48 230 2.8 5/8" 48 230 2.8 5/8" 60 255 3.2 5/8" 60 255 3.2 5/8" 80 305 3.2 1" 60 305 3.2 1" 96 355 3.4 1" 80 355 3.4 1" 100 406 3.4 1" 80 406 3.4 1" 100 455 4.0 1" 80 455 4.0 1" 100
此鋸片是以TC和ATB的設計，專於切割鐵管和不鏽鋼材料。 直徑 (mm) 刃厚 (mm) 孔徑 齒數 180 2.0 20 48 230 2.2 25.4 48 305 2.6 25.4 80 355 2.6 25.4 80 355 2.6 25.4 100 405 3.0 25.4 100
一般型鋸片：用於硬木和軟木的切割，有平齒型或交叉齒型，以20°的腹面角度之設計， 適用於桌上鋸台與多重功能鋸機。 直徑 (mm) 刃厚 (mm) 孔徑 齒數 110 2.4 5/8" 12 140 2.4 5/8" 12 152 2.4 5/8" 16 184 2.4 5/8" 16 203 2.6 5/8" 18 230 3.2 5/8" 20 255 3.2 5/8" 24 305 3.6 1" 30 355 3.6 1" 36 406 4.0 1" 40 455 4.0 1" 40
